1. When the magnetizing power supply is turned off, the capacitor can be automatically released
2. Short magnetization time, easy operation, and wide compatibility range
3. Data such as magnetizing voltage and current can be uploaded to the system
4. High magnetization saturation, capable of saturating neodymium iron boron magnets/ferrite magnets/rubber magnets
project | Technical Specifications | Remarks |
input power | AC220V±5% 50/60Hz | |
input current | ＜ 20A | |
rated power | ＜ 5KW | |
Equipment noise | ≤ 75dB | Excluding instant magnetization |
Device color | RAL7035 | customizable |
Compatibility range | Length<300mm, width<180mm, thickness<30mm | |
Device dimensions | Approximately 800 x 800 x 800mm in length, width, and height | |
changeover time | ≤ 20min | Tooling+Coil |
one | Environmental temperature: 0 ℃~40 ℃; |
two | Environmental humidity<80% (no condensation allowed); |
three | Ground load:>250KG/㎡; |
four | Gas source: pressure 0.4-0.6Mpa, flow rate 0.3m 3/ min; |
six | No dust, no oil fumes, no salt, no dripping water; |
seven | Avoid direct sunlight exposure; |
eight | No flammable or corrosive liquids or gases; |
nine | No impact or high-frequency vibration; |
ten | Location of use: Workshop open environment. |
