1. When the magnetizing power supply is turned off, the capacitor can be automatically released
2. Short magnetization time, easy operation, and wide compatibility range
3. Data such as magnetizing voltage and current can be uploaded to the system
4. High magnetization saturation, capable of saturating neodymium iron boron magnets/ferrite magnets
project | Technical Specifications | Remarks |
input power | AC220V±5% 50/60Hz | |
input current | ＜ 20A | |
rated power | ＜ 5KW | |
Equipment noise | ≤ 75dB | Excluding instant magnetization |
Device color | RAL7035 | customizable |
Device dimensions | Approximately 650 × 700 × 1600mm in length, width, and height | |
changeover time | ≤ 20min | Tooling+Coil |
one | Environmental temperature: 0 ℃~40 ℃; |
two | Environmental humidity<80% (no condensation allowed); |
three | Factory height (column top height): 2m; |
four | Ground load:>500KG/㎡; |
five | Dimensions of the transportation door for factory equipment: width 1000 x height 2000mm; |
six | Gas source: pressure 0.4-0.6Mpa, flow rate 0.3m3/min; |
seven | No dust, no oil fumes, no salt, no dripping water; |
eight | Avoid direct sunlight exposure; |
nine | No flammable or corrosive liquids or gases; |
ten | No impact or high-frequency vibration; |
eleven | Location of use: Workshop open environment. |
